Smith Fittings, located in Canberra, Australia, stands out as a top-notch manufacturer and supplier of high-quality Aluminium Bronze Sheets and Plates. Renowned for their precision engineering, durability, and resistance to corrosion, Smith Fittings delivers metal solutions that are perfect for tough industrial, marine, and engineering tasks. These Aluminium Bronze Sheets and Plates are prized for their remarkable strength, wear resistance, and non-sparking characteristics, making them ideal for essential components in challenging environments. With a strong focus on quality and prompt delivery, Smith Fittings guarantees that every sheet and plate adheres to international standards, providing engineers, fabricators, and manufacturers with reliable and long-lasting aluminium bronze solutions.
| Specifications | ASTM B505 / ASME SB505, BS EN 10088-2, en 10028-7, IS 6911, AMS 4640, UNS C63000, UNS C95800, UZ19AL6, UNS C95510, AMS 4880 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard of Sheets | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) | EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Properties | Metric | Imperial |
| Density | 7.21 g/cc | 0.260 lb/in³ |
| Melting point | 1047°C | 1917°F |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Alloy | Aluminium | Iron | Nickel | Manganese | Zinc | Arsenic |
| CuAl5 | 4.0–6.5% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | 0.4% max. |
| CuAl8 | 7.0–9.0% | 0.5% max. | 0.8% max. | 0.5% max. | 0.5% max. | |
| CuAl8Fe3 | 6.5–8.5% | 1.5–3.5% | 1.0% max. | 0.8% max. | 0.5% max. | |
| CuAl9Mn2 | 8.0–10.0% | 1.5% max. | 0.8% max. | 1.5–3.0% | 0.5% max. | |
| CuAl10Fe3 | 8.5–11.0% | 2.0–4.0% | 1.0% max. | 2.0% max. | 0.5% max. | |
| CuAl10Fe5Ni5 | 8.5–11.5% | 2.0–6.0% | 4.0–6.0% | 2.0% max. | 0.5% max. |
| Properties | Metric | Imperial |
| Hardness, Rockwell C | 27 | 27 |
| Tensile strength (M30 and O61 tempers) | 690 MPa | 100000 psi |
| Yield strength (M30 and O61 tempers) | 380 MPa | 55100 psi |
| Elongation at break (in 50 mm, 1% reduction in area) | 1.00% | 1.00% |
| Elastic modulus | 117 GPa | 17000 ksi |
| Compressive yield strength (at permanent set of 0.1%) | 450 MPa | 65300 psi |
| Compressive yield strength (at permanent set of 1%) | 880 MPa | 128000 psi |
| Poisson’s ratio | 0.34 | 0.34 |
| Charpy impact (@ 18.0 – 100°C/ -0.400 – 212°F, keyhole) | 3.00 J | 2.21 ft-lb |
| Izod impact (@ 18.0 – 100°C/ -0.400 – 212°F) | 3.00 J | 2.21 ft-lb |
| Fatigue strength (@# of cycles 1.00e+8, M30 temper) | 460 MPa | 66700 psi |
| Machinability (UNS C36000 (free-cutting brass) = 100) | 20 | 20 |
| Shear modulus | 42.3 GPa | 6140 ksi |
Aluminum bronze sheets and plates offer many key advantages, including exceptional corrosion resistance, especially in marine and acidic environments, making them ideal for offshore and underwater applications Their high tensile strength and excellent resistance anti-degradation ensures delay in demanding industries such as aerospace, automotive and heavy machinery . These compounds also have high electrical thermal conductivity, making them suitable for heat exchangers and electrical components. Moreover, the oxidation resistance and extreme temperature resistance of the aluminum lead make it a reliable candidate for a wide range of industrial applications
Smith Fittings’ Aluminium Bronze Sheets and Plates find extensive use in marine hardware, propellers, valve components, pump parts, and chemical processing equipment, thanks to their corrosion resistance and strength. They are also well-suited for aerospace fittings, heavy machinery, and industrial applications where wear resistance and non-sparking features are essential. With outstanding mechanical properties, durability, and a long service life, Aluminium Bronze Sheets and Plates offer engineers and fabricators dependable material solutions for high-performance and demanding operational settings.
