ASTM A242 Corten Steel is a weathering steel alloy primarily made up of carbon (0.12% max), manganese (0.70–1.35%), phosphorus (0.07–0.15%), sulfur (0.03% max), along with trace amounts of chromium, nickel, and copper. This unique composition gives it remarkable mechanical properties, such as high tensile and yield strength, toughness, and resistance to atmospheric corrosion. The steel naturally develops a protective oxide layer that minimizes maintenance needs. Smith Fittings provides ASTM A242 Corten Steel Sheets and Plates with exact dimensions and consistent quality, making them perfect for outdoor structural and decorative applications that demand durability, strength, and long-term performance.
Grade : ASTM A242 Type 1 Corten Steel Plates
Standard : ASTM A242 / ASME SA242
Width : 750mm to 1500mm,
Length : 2500mm to 12000mm
Thickness : 0.8MM to 50mm
Type : Corten Steel / High-Strength Low-alloy Structural Steel
Process : Hot-Rolled (HR)
| Grade ASTM A242 TYPE 1 | C | Mn | Cr | Si | CEV | S | Cu | P |
| Max 0.12 | Max 1 | 0.3-1.25 | Max 0.75 | Max 0.52 | Max 0.03 | 0.25-0.55 | 0.06 – 0.15 |
Grade | Min. Yield Strength Mpa | Tensile Strength MPa | Impact | ||||||||
| A242 Type1 | Nominal Thickness (mm) | Nominal Thickness (mm) | degree | J | |||||||
| Thick mm | ≤16 | >16 ≤40 | >40 ≤63 | >63 ≤80 | >80 ≤100 | >100 ≤150 | ≤3 | >3 ≤100 | >100 ≤150 | -20 | 27 |
| A242 Type1 | 355 | 345 | …. | …. | …. | …. | 510-680 | 470-630 | …. | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Josh Sheets and Plates based in Midland, Australia, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
ASTM A242 Corten Steel Sheet and Plate offers several advantages, including exceptional resistance to corrosion and weathering, making it ideal for outdoor and architectural applications. Its self-healing patina forms over time, protecting the steel from further degradation. This steel also provides high strength, durability, and a distinctive rustic appearance, enhancing the aesthetic value of structures. Additionally, it requires minimal maintenance due to its ability to withstand harsh environmental conditions. Corten steel is also cost-effective in the long run, as it reduces the need for frequent coating or replacement.
Yes, we offer custom sizes for ASTM A242 Corten Steel Sheet and Plate to meet specific project needs. Our team at Josh Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
You’ll find ASTM A242 Corten Steel Sheets and Plates commonly used in bridges, building cladding, architectural façades, outdoor sculptures, and landscaping structures, thanks to their impressive corrosion resistance and aesthetic charm. They’re particularly well-suited for infrastructure projects that face diverse weather conditions, ensuring long-lasting durability and minimal upkeep. Moreover, these sheets and plates are ideal for industrial and structural applications that require strength and resistance to atmospheric corrosion. Smith Fittings’ ASTM A242 Corten Steel products are designed to meet these needs effectively.
